Specifications
| Lifting cap. arm in/out | 820 / 200 kg |
|---|---|
| Lifting height | 4,400 mm |
| Extension of arm | 2 x 830 mm |
| Tip from horizontal | 42o back / 86o fwd. |
| Side shift | 100 mm |
| Charging voltage | 230V / 110V |
| Charging time | Approx. 8 hrs. |
| Battery | 4 x 134 Ah AGM |
| Running period | Up to 8 hrs |
| Front-wheel drive | 2000 W AC |
| Suction pads | 4 x Ø400mm & 2 x Ø300mm |
| Width | 1,010 mm |
| Curb weight | 1,300 kg |
| Class | IP 65 |
